HSJ1 Shawmut 1A 600Vac 500Vdc High Speed Fuse
  • HSJ1 Shawmut 1A 600Vac 500Vdc High Speed Fuse
  • HSJ3 Shawmut 3A 600Vac 500Vdc High Speed Fuse

HSJ17-1/2 Shawmut 17-1/2-A 600Vac 500Vdc High Speed Fuse

HSJ17-1/2
Mersen
  • Designed For Solid State Motor Starters (Soft Starters)
  • Low I2T For Protections Of Diodes, SCR's, GTO's, And Solid State Relays
  • Excellent Cycling Ability For Frequent On / Off Devices
  • Interrupt Amp Rating 200K@600Vac 100K@500Vdc
  • Can Be Used In Combination To Provide Branch Circuit Protection Per National Electric Code And Semiconductor Devices At The Same Time
  • UPC 78200133167
$33.07
Quantity
4 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

THE FOLLOWING MERSEN ULTRASAFE FUSE HOLDERS CAN BE USED:

  • US3J1  Single Pole
  • US3J1i Single Pole With Blown Fuse Indicator
  • US3J2  Two Pole
  • US3J2i Two Pole With Blown Fuse Indicator
  • US3J3  Three Pole
  • US3J3i Three Pole With Blown Fuse Indicator
Product Details
HSJ17-1/2
0
4 Items
