ATQR1 Shawmut 1A 600Vac Time-Delay Fuse

Class J Fast Acting And Current Limiting For Low Peak Let-Thru Current Rated Inturrpting Capacity 200Ka@600Vac 100Ka@300Vdc Unique Physical Dimensions Provides Protection From Substitution Protection For Capacitors, Load Centers, Circuit Breakers, And Feeder Circuits UPC 78200196034

Class CC Rated 300Vdc and 600Vac Rated Inturrupting Capacity 200Ka@600Vac 100Ka@300Vdc Rejection Design Prevents Substitution By Lesser Rated Fuses Can Be Used With Ultrasafe Type UCC Fuse Holders Ideally Suited For High Inrush Currents of Control Transformers, and Solenoids Ultrasafe Is A Trademark Of Mersen Fuses a/k/a Ferraz-Shawmut And Gould Fuses...

Primarily Used For Semiconductor Protection 13/32"OD x 1-1/2"L  (10mm x 38mm) 600V ac/dc Rated Inturrupting Rating 200Ka@600Vac  100Ka@600Vdc I²T Clearing Rating 100k@600Vac= 860A²Seconds I²T Clearing Rating 100K@600Vdc = 520A²Seconds Same as Bussman FWP-30A14F

Time-Delay 12-Seconds at 200% Of Fuse Ampere Rating Ideal For Circuits With High Inrush Currents Supplemental Protection For Solenoids, Motors, And Transformer Circuits 13/32"OD x 1-1/2"L (10mm x 38mm) 10K Amp Interupting Rating Available in Amerages Up To 30A Can Be Used With UltraSafe Fuse Holders UPC 78200174335
