DCT15-2 Shawmut Fuse 15A 750Vac 1000Vdc

Time-Delay 12-Seconds at 200% Of Fuse Ampere Rating Ideal For Circuits With High Inrush Currents Supplemental Protection For Solenoids, Motors, And Transformer Circuits 13/32"OD x 1-1/2"L (10mm x 38mm) 10K Amp Interupting Rating Available in Amerages Up To 30A Can Be Used With UltraSafe Fuse Holders UPC 78200190602

Primarily Used For Semiconductor Protection 13/32"OD x 1-1/2"L  (10mm x 38mm) 600V ac/dc Rated Inturrupting Rating 200Ka@600Vac  100Ka@600Vdc I²T Clearing Rating 100k@600Vac= 110A²Seconds I²T Clearing Rating 100K@600Vdc = 70A²Seconds Same as Bussman FWC-10A10F

Class J Fast Acting And Current Limiting For Low Peak Let-Thru Current Rated Inturrpting Capacity 200Ka@600Vac 100Ka@300Vdc Unique Physical Dimensions Provides Protection From Substitution Can Be Used With IP20 Rated Ultrasafe Fuse Holders  Ultrasafe Is A Trademark of Mersen Fuses a/k/a Ferraz-Shawmut and Gould Fuses Inc. UPC 78200196006

Class CC Rated 300Vdc and 600Vac Rated Inturrupting Capacity 200Ka@600Vac 100Ka@300Vdc Rejection Design Prevents Substitution By Lesser Rated Fuses Can Be Used With Ultrasafe Type UCC Fuse Holders Ideally Suited For High Inrush Currents of Control Transformers, and Solenoids Ultrasafe Is A Trademark Of Mersen Fuses a/k/a Ferraz-Shawmut And Gould Fuses...
