ATM15 SHAWMUT FUSE 15A 600Vac-dc Fast Acting

Specifically Designed For Protection of Photovoltaic Systems Protects Battery Charge Controllers, Inverters, In-Line PV Cells 10K Amp Inturrupt Rating At 1000V-dc Low Fault Current Interrupting Capability Temperature Cycle Withstand Capability Can Be Used With Ultrasafe Fuse Holders UPC 78200142992

Class CC IEC Type 2 No Damage Protection Fuse Rejection Design Prevents Substitution By Lesser Rated Fuses  Rated Inturrupting Capacity 200Ka@600Vac 100Ka@600Vdc Fast-Acting And Very Current-Limiting Can Be Used With Ultrasafe Type UCC Fuse Holders Ultrasafe Is A Trademark Of Mersen Fuses a/k/a Ferraz-Shawmut And Gould Fuses UPC 78200190384

Primarily Used For Semiconductor Protection 13/32"OD x 1-1/2"L  (10mm x 38mm) Rated 700Vac 500Vdc Inturrupting Rating 160Ka@690Vac I²T Clearing Rating 30A²Seconds @690Vac I²T Clearing Rating 20A²Seconds @480Vac I²T Clearing Rating 12A²Seconds @240Vac I²T Clearing Rating 10A²Seconds @120Vac

Class CC  IEC Type 2 No Damage Protection Fuse Rated Inturrupting Capacity 200Ka@600Vac 100Ka@300Vdc Excellent Cycling Ability Recommended for Small Motors And Resistive Load Contactors  Rejection Design Prevents Replacement Errors Can Be Used With Ultrasafe Type UCC Fuse Holders Ultrasafe Is A Trademark Of Mersen Fuses a/k/a Ferraz-Shawmut And Gould...
