ATM1/2 SHAWMUT FUSE 1/2-A 600Vac-dc Fast Acting

Amp-Trap Class J Time Delay Fuse SmartSpot Indicator Provides Visual For Blown Fuse Most Current-Limiting UL Class Fuse IEC Type 2 No Damage Protection For All Types Of Loads Interrupt Amp Rating 200K@600Vac 100K@500Vdc High Grade Silica Filler Ensures Fast Arc Quenching Can Be Used With IP20 Rated Ultrasafe Fuse Holders UPC 78200196305

Primarily Used For Semiconductor Protection 13/32"OD x 1-1/2"L  (10mm x 38mm) Rated 700Vac 500Vdc Inturrupting Rating 160Ka@690Vac I²T Clearing Rating 35A²Seconds @690Vac I²T Clearing Rating 23A²Seconds @480Vac I²T Clearing Rating 14A²Seconds @240Vac I²T Clearing Rating 11A²Seconds @120Vac

Class CC IEC Type 2 No Damage Protection Fuse Rejection Design Prevents Substitution By Lesser Rated Fuses  Rated Inturrupting Capacity 200Ka@600Vac 100Ka@600Vdc Fast-Acting And Very Current-Limiting Can Be Used With Ultrasafe Type UCC Fuse Holders Ultrasafe Is A Trademark Of Mersen Fuses a/k/a Ferraz-Shawmut And Gould Fuses UPC 78200190385

Primarily Used For Control Circuits, Control Transformers, And Small Motors 13/32"OD x 1-1/2"L (10mm x 38mm) 10K Amp Interrupting Rating Fast Acting On Short Circuits Moderate Time-Delay On Inrush Currents Also Available Up To 15Amps Can Be Used With UltraSafe Fuse Holders UPC 78200190137
